AL-KO Reinluft Entstauber PowerUnit 200P

depending on equipment, accessories, and services


AL-KO clean air dust collector powerunit 200P

Machine valution, machine purchase, machine sale of woodworking machines

AL-KO Reinluft PowerUnit 200P Dust Collector, built in 2016, CE sign, suitable for wood and wood composites, paper, plastics, metal, stone, and much more, integrated pre-separator to protect the filters, PLC control for manual start and automatic start via a potential-free contact, manually triggered cleaning cycle, optionally with machine detection via a potential-free contact or transformer coil and slide valve control (for 24V electro-pneumatic systems) with bypass control,

200 mm intake port, 3.0 kW 400 V motor, max. airflow 3,010 m³/h, airflow at the inlet at 20 m/s: 2,262 m³/h, negative pressure at the inlet at 20 m/s: 2,563 Pa (when dusty and after cleaning), filter area 13.8 m², 35 filters, each Ø 125 mm x 1,000 mm, filter material: polyester needle felt, Cat. M – electrically conductive – washable, residual dust content H3 (< 0.1 mg/m³), AL-KO OPTI JET® filter cleaning with compressed air, max. sound pressure level 72 dB(A) (free-field measurement according to DIN EN ISO 11201, measured at a distance of 1 m), Net/gross chip collection volume 165 / 241 liters, Siemens Micro-PLC-LOGO PLC control, 5 m cable with 16A CEE plug and phase reverser, airflow monitoring via an adjustable differential pressure sensor with a warning light on the control box, dimensions (L x W x H) 2,296 x 830 x 2,050 mm, mobile on 4 plastic casters (125 mm)—two of which are swivel casters, one with a lock, weight 470 kg, operating side can be changed to the right or left at any time

AL-KO clean air dust collector powerunit 200P

AL-KO clean air dust collector powerunit 200P

To avoid trouble, please note the following important information:

All prices are net plus statutory VAT.

Sales exclusively to commercial customers.

Some of the machines contain accessories that are subject to a surcharge. Reservations only with a deposit. All used and demonstration machines are sold as is, with no warranty.

Only written agreements apply.

Payable immediately before or at the latest upon delivery or by leasing (by arrangement). Delivery difficulties (difficult entry into the building, lack of equipment for unloading, etc.) must be clarified beforehand. Delivery from Langen warehouse. Orders are subject to change and are checked by the management. The date of receipt of the orders is decisive in the case of multiple sales. Only the first order is valid! Delivery only after clarification of payment! Furthermore, our terms and conditions apply. You can find our terms and conditions on our website or on our order confirmations.
